You can condition 36 tubes simultaneously.

Tube fittings can be easily removed and removed without the hassle of loosening and locking.

When the adsorption pipe is connected to each port, the flow rate flows, and when disconnected, the flow rate is blocked, which complements the disadvantages of the existing Ball Flow Meter method.

When conditioning starts, the tube holder automatically rises and moves to the oven, and after conditioning, it automatically moves down the oven to cool down to room temperature.

Temperature programmable in 10 steps allows for step-by-step conditioning.

180’ rotating oven type

Fast cooling with cooling fan

Gas saving function

Automatic shut down function (fire prevention)

Max temperature : 400°C

Conditioning tubes : 36 tubes

Gas flow control : Pressure Control

Temperature control : PID

Temperature programming step : 10 step

Cooling time : within 10 minute

Automatic conditioning & cooling : Automatic Up & Down

Power : 220VAC, 50/60Hz, 1.2kW

Dimension : 390x420x470 (WxDxH)
